Routing:
Layer 3 Advanced
Захранване:
Dual field-replaceable power supplies, Default primary AC power supply: PWR-C5-125WAC
MAC адреси:
32000 MAC address
Размери (Ш, Д, В), mm:
445 x 350 x 44
Промоция:
Специална цена. Валидност до 24.10.2025г.
Основни портове, тип:
24x10/100/1000Base-T
Памет (Flash, RAM):
Flash memory: 4 GB RAM: 4 GB DRAM
VLAN (брой, стандарти):
VLAN IDs: 4096 IEEE 802.1Q VLAN
L2 мрежови стандарти:
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3bz, IEEE 802.3ad, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.1x-Rev, IEEE 802.3x
Power Over Ethernet (PoE):
No
Капацитет за маршрутизиране/превключване, Gbps:
128 Gbps
Fans:
Field-Replaceable Units (FRU) redundant
Stackable:
Cisco StackWise-160 stacking ports: copper-based Cisco StackWise cabling, Stacking hardware (C9200-STACK-KIT=), Supported stack members: Other C9200 models with same license level (8 Number of members)
IPv6 functionality:
IPv6 routing (using OSPFv3 and EIGRPv6) is supported in hardware for maximum performance IPv6 addressing is supported on interfaces with appropriate show commands for monitoring and troubleshooting
Други:
Задължителен е минимум 3-годишен лиценз DNA Essentials.
Сигурност:
Enhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems
Пропускателна способност, Mpps:
190.4 Mpps
QoS:
Granular wireless bandwidth management and fair sharing, 802.1p Class of Service (CoS) and Differentiated Services Code Point (DSCP) field classification, Shaped Round Robin (SRR) scheduling, Committed Information Rate (CIR), and eight egress queues per
L3 мрежови стандарти:
IP unicast routing protocols: Static, Routing Information Protocol Version 1 [RIPv1], and RIPv2, RIPng, Open Shortest Path First [OSPF]
Опция за монтаж:
Rackmount
Управление:
SNMPv1, SNMPv2c, and SNMPv3 RMON I and II standards Internet Group Management Protocol (IGMP) CLI TCP UDP
Свободни (10GB) слотове:
Modular uplink options (C9200-NM-4G, C9200-NM-4X)
